Hayabusa Wire

Features

New wire electrode created by using Sodick's unique construction methods: Proprietary method using diffusion reaction overcomes the disadvantage of inferior surface roughness to brass wire in processing time with zinc-coated wire.
This new wire electrode wire combines a highly conductive brass wire and a highly emissive zinc wire.
High speed machining: Discharge efficiency is higher and the speed is 10-50% faster than brass wire electrode. Even as the machining speed has increased, accuracy equivalent to that of brass wire can be obtained.
Environmentally-friendly: Reduction of wire consumption and electricity cost by shortening machining time.
It is also possible to perform eco-machining with reduced wire usage by taking advantage of the feature of less wire breakage even when wire feed speed is reduced.

※You can see the entire Directors and Audit & Supervisori Board Membersable by scrolling horizontally.

※You can see the entire Directors and Audit & Supervisori Board Membersable by scrolling horizontally.

Order No.	Wire Diameter		Weight		Product name	Spool	Qty / Box	Qty / Pallet
Order No.	(φmm)	(in)	(kg)	(lb)	Product name	Spool	Qty / Box	Qty / Pallet
J00131A	0.10	0.004	3	6.6	HAYABUSA P100 P5-3	P5	4	240
J00132A	0.15	0.006	3	6.6	HAYABUSA 150 P5-3	P5	4	240
J00133A	0.20	0.008	5	11	HAYABUSA 200 P5-5	P5	4	240
J13785A			6	13.2	HAYABUSA 200 P5-6	P5	4	240
J00134A			20	44.1	HAYABUSA 200 P20-20	P20	1	54
J00135A	0.25	0.010	5	11	HAYABUSA 250 P5-5	P5	4	240
J13786A			6	13.2	HAYABUSA 250 P5-6	P5	4	240
J00136A			20	44.1	HAYABUSA 250 P20-20	P20	1	54
J00137A	0.30	0.012	5	11	HAYABUSA 300 P5-5	P5	4	240
J13787A			6	13.2	HAYABUSA 300 P5-6	P5	4	240
J00138A			20	44.1	HAYABUSA 300 P20-20	P20	1	54
